Product Description
Size | 8-32 UNC |
Shank diameter max./min. | 0.1640"/0.1585" |
Pitch | 32 tpi |
Length (measured from under the head) |
5/8" |
Thread length | Fully threaded |
Material | Stainless steel A2-70 (304) |
Finish | Natural |
Head diameter max./min. | 0.270"/0.262" |
Head height max./min. | 0.164"/0.159" |
Key size | 9/64" |
Standard | ASME B18.3 1998 |
